Direct replacement gasoline engine suitable for Honda suitable for the 4-stroke GX160 5.5hp
Direct replacement gasoline engine suitable for Honda suitable for the 4-stroke GX160 5.5hp
- ✓ Price includes VAT — no surprises later
- ✓ Fast shipping from our own stock
- ✓ 100% new, aftermarket in OE quality
- ✓ 2-year warranty against manufacturing defects
Product Description
This complete petrol engine is a direct replacement for the Honda 4-stroke GX160 5.5hp engine, suitable for a wide range of applications such as generators, pumps, and go-kart/garden machinery.
Specifications
- Engine Type: 168F, single-cylinder OHV 4-stroke, air-cooled
- Bore x Stroke: 68 x 45 mm
- Displacement: 168 cc
- Compression Ratio: 8.5:1
- Max Power: 5.5 hp / 4.1 kW
- Rated Power: 4.0 hp / 3.0 kW
- Starting System: Recoil start
- Engine Oil Capacity: 0.6 litres
- Fuel Capacity: 3.6 litres
- Dimensions: 330 (H) x 360 (L) x 305 (W) mm
- Air Filter: Semi-dry
- Engine Rotation: Counter-clockwise
- Crankshaft/Drive Shaft Thread Diameter: 7 mm
- Overall Length: 360 mm
- Overall Width: 305 mm
- Overall Height: 330 mm
- Drive Shaft Length: 58.5 mm
- Distance between lower mounting holes (clutch side): 165 mm
- Distance between lower mounting holes (starter side): 165 mm
- Warranty: 1 year on manufacturing defects
Features
- Recoil start with manual choke and fuel shut-off
- Durable, reliable and versatile for multiple domestic and commercial applications
- Engine is supplied new and without engine oil; oil must be added before use according to the specification table
Please Note
Before purchasing, carefully check the diameter and length of the drive shaft/crankshaft end of your current engine, as the source states conflicting measurements.
Checking Fitment
Always check the original OEM part number, year of manufacture, engine code, and your vehicle's trim level before ordering, as differences may exist per trim. If you are unsure whether this part fits your vehicle, please feel free to contact us before purchasing.
