Forged 4340 EN24 H-Beam Connecting Rods Bolts compatible for Honda/ Acura H23/F22 2.2L 2.3L
Forged 4340 EN24 H-Beam Connecting Rods Bolts compatible for Honda/ Acura H23/F22 2.2L 2.3L
- ✓ Price includes VAT — no surprises later
- ✓ Fast shipping from our own stock
- ✓ 100% new, aftermarket in OE quality
- ✓ 2-year warranty against manufacturing defects
Application
Compatible for Honda/Acura H23/F22 2.2L 2.3L
Specification
*Type: Forged 4340 aircraft chrome moly quality steel for racing
*H-beam Conrods Quantity: 4 Pieces as showing in picture
*Bolts: Including ARP 2000 3/8" bolts (Note: Extra cost for upgrading to ARP L19 bolts)
*The connecting rods all include ARP 2000 bolts, which are rated at 220,000 psi, and the optional ARP L19 material at 260,000 psi is available as an upgraded product.
*Advertised Horsepower Rating:200HP/piece
*Top acceleration: 9000rpm
*package size：28CM*21CM*10CM
Dimension
Center to center length:141.5mm
Big end diameter:51mm
Small end diameter:22mm
Big end width:23.8mm
Small end width:23.8mm
Feature
1. TüV Certification Con Rods；
2. H-Beam design reduces weight without compromising strength；
3. Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers；
4. 100% CNC machined,Precision rod cap alignment dowels；
5. Bores finished to +/- .01 mm；
6. Balanced to within +/- 1 g per rod；
7. Each rod is magnetic particle tested to ensure free of flaws；
8. 100% X-rayed, sonic tested；
9. Custom-made Service.
Note
*Professional installation is highly recommended ；
*Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
Warranty: one year warranty for any manufacturing defect
