4 x Forged Connecting Rods compatible for Triumph TR3 TR4 Con Rod Bielle ARP 2000 Bolts
4 x Forged Connecting Rods compatible for Triumph TR3 TR4 Con Rod Bielle ARP 2000 Bolts
- ✓ Price includes VAT — no surprises later
- ✓ Fast shipping from our own stock
- ✓ 100% new, aftermarket in OE quality
- ✓ 2-year warranty against manufacturing defects
Application
Compatible for Triumph TR3 (2.0L / 2.2L I4) – Fits 4340 forged connecting rod
compatible for Triumph TR4 (2.1L / 2.2L I4) – Fits 4340 forged connecting rod
Specification
Beam Style: H-beam Street/Strip
Material: 4340 Chromoly Steel
Finish: Shot-peened
Wrist Pin Style: Floating
Clearanced for Stroker: Yes
Cap Retention Style: Through-bolt
Connecting Rod Bolt Brand: ARP
Connecting Rod Bolt Diameter: 3/8"
Connecting Rod Bolt Material: Alloy Steel
Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
Connecting Rod Bolt Head Style: 12-point
CNC Machined: High Precision
Rod Cap Alignment: Precision dowels
Bore Tolerance: ±0.005 mm
Balancing: ±1 gram per rod
Weight Matched Set: Yes
Remanufactured: No
Testing: Magnafluxed, X-rayed, Ultrasonically tested
Heat Treated: Yes
Dimension
Connecting Rod Length Center to Center: 158.75mm/6.250in
Approximate Connecting Rod Weight:652g
Big End Bore Diameter: 56.72mm/2.233in
Pin End Bore Diameter: 22.00mm/0.866in
Big End Width: 29.85mm/1.175in
Small End Width: 26.90mm/1.059in
Performance Ratings
Advertised Horsepower Rating: 200HP/piece
Advertised RPM Rating: 9000rpm
Packaging
Quantity: Sold as a set of 4
Package Size: 28CM*20CM*10CM
